Slam Lifting AMR Robot
Slam lifting amr robot is an underride lifting AGV utilizing SLAM navigation for autonomous mobility and intelligent obstacle avoidance. Its infrastructure-free operation ensures reliable rack / cart transfer throughout the production cycle – from raw material intake to finished goods shipment.
Features
Slam lifting amr robot is an underride lifting AGV utilizing SLAM navigation for autonomous mobility and intelligent obstacle avoidance. Its infrastructure-free operation ensures reliable rack / cart transfer throughout the production cycle – from raw material intake to finished goods shipment.
Products Description
As a Skybridge Robot flagship solution, slam lifting amr robot optimizes industrial logistics through SLAM-enabled ±5mm precision positioning and adaptive path planning. Deployed across safety-critical sectors including lithium battery production, automotive manufacturing, FMCG, 3C electronics, and pharmaceuticals.
Specifications
|
Model |
R2-22B |
|
Dimension |
L940*W650*H253 (mm) |
|
Max payload |
1000kg |
|
Weight |
150kg |
|
Rotation Diameter |
1087mm |
|
Relative Rotation |
YES |
|
Size of Lifting Platform |
860*600mm |
|
Max Lifting Distance |
60mm |
|
Navigation mode |
QR / SLAM |
|
Navigation accuracy |
±10mm / ±15mm |
|
Stop accuracy |
±5mm / ±10mm |
|
Stop Angle Accuracy |
±1° |
|
Moving direction |
Forward , backward , rotate |
|
Drive mode |
Two-wheel differential drive |
|
Acceleration |
0.5m/s² |
|
Max moving speed |
2m/s |
|
Max climbingcapability |
≤3° |
|
Battery type |
Lithium battery |
|
Charging mode |
Collision charging |
|
Charging time |
Charging time after full discharging≤1H |
|
Rated endurance |
4H |
|
Communication Method |
WiFi / 5G |
|
Safety warning |
●Light warning ●Voice broadcast |
|
Safe sensing range |
≤3m adjustable |
|
Safety protection |
●Obstacle detection sensor ahead |
|
Working temperature |
-10℃ ~ 45℃ |
|
Working Environment |
No dust, no flammable / explosive / corrosive gases |
Product Cases
Project Case: BYD Huizhou Plant Raw Material Automation
Application Scenario: 3C & Semiconductor - Core Material Pallet Handling
Core Functionality: slam lifting amr robot enables multi-point material transfer between core production and conveyor testing stations. Integrated with JRMS control systems for automated dispatching, intelligent transport, data capture, and intelligent warehousing via MES synchronization.
Project Key Advantages:
- Full Automation: MES integration achieves 100% unmanned material transport.
- AI-Powered Optimization: Autonomous task prioritization and dynamic routing with dual ±5mm precision scanners (top/bottom).
